Tutorial : Samba PDC + OpenLDAP on openSUSE 11.1 – Part 2

Previous Tutorial : Tutorial : Samba PDC + OpenLDAP on openSUSE 11.1 – Part 1, Installing Base System & Configuring Samba

On previous tutorial, we have installing base system and setting up Samba configuration. Now, we will go to LDAP configuration.
LDAP on openSUSE 11.1 has a different style than the previous setting on openSUSE 10.3. openSUSE 11.1 use the dynamic configuration so the LDAP setting itself will be saved on LDAP database as described on YAST LDAP configuration :

#
# Note: The OpenLDAP configuration has been created by YaST. YaST does not
#       use /etc/openldap/slapd.conf to store the OpenLDAP configuration anymore.
#       YaST uses OpenLDAP’s dynamic configuration database (back-config) to
#       store the LDAP server’s configuration.
#       For details about the dynamic configuration backend please see the
#       slapd-config(5) manpage or the OpenLDAP Software 2.4 Administrator’s Guide
#       located at /usr/share/doc/packages/openldap2/guide/admin/guide.html
#       on this system.

What make me confused on the first attempt configuring LDAP on openSUSE 11.1 are the problem while trying to get nis.schema work. It has conflict with the built in rfc2307bis.schema. Trying to replace the nis.schema into rfc2307bis.schema bring me into another problem. AFAIK, YAST didn’t provide the option to remove rfc2307bis.schema and replace it with nis.schema (Actually, it seems that rfc2307bis.schema is an update version from nis.schema but it has not fully compatible with another configuration using nis.schema), so I decided to use the manual configuration and will not use configuration option with YAST menu.
In an email from openSUSE mailing list, I’ve read that we may also using the files configuration with YAST by change the setting OPENLDAP_CONFIG_BACKEND = “files” on /etc/sysconfig/openldap and then make a changes to /etc/openldap/slapd.conf.
In this tutorial, I’ll be using manual configuration without YAST menu and use nis.schema.

1. Create an LDAP configuration  /etc/openldap/slapd.conf with the following content :
   [code language=’cpp’]
   include /etc/openldap/schema/core.schema
   include /etc/openldap/schema/cosine.schema
   include /etc/openldap/schema/inetorgperson.schema
   include /etc/openldap/schema/nis.schema
   include /etc/openldap/schema/samba3.schema
   modulepath /usr/lib/openldap/modules/
   # moduleload back_bdb.la
   pidfile /var/run/slapd/slapd.pid
   argsfile /var/run/slapd/slapd.args
   # Samba Primary Database vavai.net
   database bdb
   suffix “dc=vavai,dc=net”
   directory /var/lib/ldap
   rootdn “cn=Manager,dc=vavai,dc=net”
   rootpw zezevavai26032006
   index entryCSN eq
   index entryUUID eq
   #access to attrs=userPassword,sambaLMPassword,sambaNTPassword
   # by self write
   # by dn=”cn=Manager,dc=vavai,dc=net” write
   # by * auth
   #access to *
   # by dn=”cn=Manager,dc=vavai,dc=net” write
   # by * read
   # Indices to maintain
   index objectClass eq
   index cn pres,sub,eq
   index sn pres,sub,eq
   index uid pres,sub,eq
   index displayName pres,sub,eq
   index uidNumber eq
   index gidNumber eq
   index memberUID eq
   index sambaSID eq
   index sambaPrimaryGroupSID eq
   index sambaDomainName eq
   index default sub
   [/code]
2. Create /etc/ldap.conf configuration :
   [code language=’cpp’]
   # LDAP Master
   host server.vavai.net
   base dc=vavai,dc=net
   binddn cn=Manager,dc=vavai,dc=net
   bindpw zezevavai26032006
   bind_policy soft
   pam_password exop
   nss_base_passwd ou=People,ou=Users,dc=vavai,dc=net?one
   nss_base_shadow ou=People,ou=Users,dc=vavai,dc=net?one
   nss_base_passwd ou=Computers,ou=Users,dc=vavai,dc=net?one
   nss_base_shadow ou=Computers,ou=Users,dc=vavai,dc=net?one
   nss_base_group ou=Groups,dc=vavai,dc=net?one
   ssl no
   [/code]
3. Create /etc/nsswitch.conf :
   [code language=’cpp’]
   passwd: files ldap
   shadow: files ldap
   group: files ldap
   hosts: files dns wins
   networks: files dns
   [/code]
4. Create /var/lib/ldap/DB_CONFIG
   [code language=’cpp’]
   set_cachesize 0 150000000 1
   set_lg_regionmax 262144
   set_lg_bsize 2097152
   set_flags DB_LOG_AUTOREMOVE
   [/code]
5. Create an ldif file to fill the initial LDAP database. Saved it as domainname.ldif (in my case : vavai.ldif) and then copy-paste the following content. Don’t forget to replace S-1-2-33-4444444444-5555555555-6666666666 with your Samba SID (See previous tutorial)
   [code language=’cpp’]
   # LDAP INITIAL DATA
   # SID S-1-2-33-4444444444-5555555555-6666666666.
   dn: dc=vavai,dc=net
   objectClass: dcObject
   objectClass: organization
   dc: vavai
   o: VAVAI
   description: Posix and Samba LDAP Identity Database
   dn: cn=Manager,dc=vavai,dc=net
   objectClass: organizationalRole
   cn: Manager
   description: Directory Manager
   dn: cn=syncuser,dc=vavai,dc=net
   objectClass: person
   cn: syncuser
   sn: syncuser
   userPassword: SyncUser
   dn: cn=sambaadmin,dc=vavai,dc=net
   objectClass: person
   cn: sambaadmin
   sn: sambaadmin
   userPassword: SambaAdmin
   dn: cn=mailadmin,dc=vavai,dc=net
   objectClass: person
   cn: mailadmin
   sn: mailadmin
   userPassword: MailAdmin
   dn: ou=Users,dc=vavai,dc=net
   objectClass: top
   objectClass: organizationalUnit
   ou: Users
   dn: ou=People,ou=Users,dc=vavai,dc=net
   objectClass: top
   objectClass: organizationalUnit
   ou: People
   dn: ou=Computers,ou=Users,dc=vavai,dc=net
   objectClass: top
   objectClass: organizationalUnit
   ou: Computers
   dn: ou=Groups,dc=vavai,dc=net
   objectClass: top
   objectClass: organizationalUnit
   ou: Groups
   dn: ou=Domains,dc=vavai,dc=net
   objectClass: top
   objectClass: organizationalUnit
   ou: Domains
   dn: sambaDomainName=VAVAI.NET,ou=Domains,dc=vavai,dc=net
   objectClass: sambaDomain
   objectClass: sambaUnixIdPool
   uidNumber: 1000
   gidNumber: 1000
   sambaDomainName: VAVAI.NET
   sambaSID: S-1-2-33-4444444444-5555555555-6666666666
   sambaAlgorithmicRidBase: 1000
   structuralObjectClass: sambaDomain
   dn: cn=Domain Admins,ou=Groups,dc=vavai,dc=net
   objectClass: posixGroup
   objectClass: sambaGroupMapping
   gidNumber: 512
   cn: Domain Admins
   sambaSID: S-1-2-33-4444444444-5555555555-6666666666-512
   sambaGroupType: 2
   displayName: Domain Admins
   description: Domain Administrators
   dn: cn=Domain Users,ou=Groups,dc=vavai,dc=net
   objectClass: posixGroup
   objectClass: sambaGroupMapping
   gidNumber: 513
   cn: Domain Users
   sambaSID: S-1-2-33-4444444444-5555555555-6666666666-513
   sambaGroupType: 2
   displayName: Domain Users
   description: Domain Users
   dn: cn=Domain Guests,ou=Groups,dc=vavai,dc=net
   objectClass: posixGroup
   objectClass: sambaGroupMapping
   gidNumber: 514
   cn: Domain Guests
   sambaSID: S-1-2-33-4444444444-5555555555-6666666666-514
   sambaGroupType: 2
   displayName: Domain Guests
   description: Domain Guests
   dn: cn=Domain Computers,ou=Groups,dc=vavai,dc=net
   objectClass: posixGroup
   objectClass: sambaGroupMapping
   gidNumber: 515
   cn: Domain Computers
   sambaSID: S-1-2-33-4444444444-5555555555-6666666666-515
   sambaGroupType: 2
   displayName: Domain Computers
   description: Domain Computers
   dn: cn=Administrators,ou=Groups,dc=vavai,dc=net
   objectClass: posixGroup
   objectClass: sambaGroupMapping
   gidNumber: 544
   cn: Administrators
   sambaSID: S-1-2-33-4444444444-5555555555-6666666666-544
   sambaGroupType: 5
   displayName: Administrators
   description: Administrators
   dn: cn=Account Operators,ou=Groups,dc=vavai,dc=net
   objectClass: posixGroup
   objectClass: sambaGroupMapping
   gidNumber: 548
   cn: Account Operators
   sambaSID: S-1-2-33-4444444444-5555555555-6666666666-548
   sambaGroupType: 5
   displayName: Account Operators
   description: Account Operators
   dn: cn=Print Operators,ou=Groups,dc=vavai,dc=net
   objectClass: posixGroup
   objectClass: sambaGroupMapping
   gidNumber: 550
   cn: Print Operators
   sambaSID: S-1-2-33-4444444444-5555555555-6666666666-550
   sambaGroupType: 5
   displayName: Print Operators
   description: Print Operators
   dn: cn=Backup Operators,ou=Groups,dc=vavai,dc=net
   objectClass: posixGroup
   objectClass: sambaGroupMapping
   gidNumber: 551
   cn: Backup Operators
   sambaSID: S-1-2-33-4444444444-5555555555-6666666666-551
   sambaGroupType: 5
   displayName: Backup Operators
   description: Backup Operators
   dn: cn=Replicators,ou=Groups,dc=vavai,dc=net
   objectClass: posixGroup
   objectClass: sambaGroupMapping
   gidNumber: 552
   cn: Replicators
   sambaSID: S-1-2-33-4444444444-5555555555-6666666666-552
   sambaGroupType: 5
   displayName: Replicators
   description: Replicators
   [/code]
6. Import the LDIF file into LDAP database with the following command (don’t forget to replace vavai.ldif with your own) :
   [code language=’cpp’]
   slapadd -v -l vavai.ldif -f /etc/openldap/slapd.conf
   [/code]
   It should be response with the process information as below :

   added: “dc=vavai,dc=net” (00000001)
   added: “cn=Manager,dc=vavai,dc=net” (00000002)
   added: “cn=syncuser,dc=vavai,dc=net” (00000003)
   added: “cn=sambaadmin,dc=vavai,dc=net” (00000004)
   added: “cn=mailadmin,dc=vavai,dc=net” (00000005)
   added: “ou=Users,dc=vavai,dc=net” (00000006)
   added: “ou=People,ou=Users,dc=vavai,dc=net” (00000007)
   added: “ou=Computers,ou=Users,dc=vavai,dc=net” (00000008)
   added: “ou=Groups,dc=vavai,dc=net” (00000009)
   added: “ou=Domains,dc=vavai,dc=net” (0000000a)
   added: “sambaDomainName=VAVAI.NET,ou=Domains,dc=vavai,dc=net” (0000000b)
   added: “cn=Domain Admins,ou=Groups,dc=vavai,dc=net” (0000000c)
   added: “cn=Domain Users,ou=Groups,dc=vavai,dc=net” (0000000d)
   added: “cn=Domain Guests,ou=Groups,dc=vavai,dc=net” (0000000e)
   added: “cn=Domain Computers,ou=Groups,dc=vavai,dc=net” (0000000f)
   added: “cn=Administrators,ou=Groups,dc=vavai,dc=net” (00000010)
   added: “cn=Account Operators,ou=Groups,dc=vavai,dc=net” (00000011)
   added: “cn=Print Operators,ou=Groups,dc=vavai,dc=net” (00000012)
   added: “cn=Backup Operators,ou=Groups,dc=vavai,dc=net” (00000013)
   added: “cn=Replicators,ou=Groups,dc=vavai,dc=net” (00000014)

   If you found an error while trying to import the ldif file, check your ldif file to see if there’s a typo.

7. Setting up the owner for LDAP folder :
   [code language=’cpp’]
   chown -R ldap.ldap /var/lib/ldap/
   [/code]
8. Create Samba primary password
   [code language=’cpp’]
   smbpasswd -w zezevavai26032006
   [/code]

Samba should be response with the following message :
Setting stored password for “cn=sambaadmin,dc=vavai,dc=net” in secrets.tdb

We will continue to next article : Tutorial : Samba PDC + OpenLDAP on openSUSE 11.1 – Part 3, Setting up smbldap-tools and LAM (LDAP Accounts Manager)
